Year of manufacture 1997
Working dimension X 3375
Working dimension Y 1252
Working dimension Z 200
Number of routing spindles 1
Main motor power kW 9
Rotation speed max rpm 24000
Torque support 1
Rotational axes C-axis
Tool clamping system HSK-F63
Tool changing positions 8
Borer vertical 19
Horizontal drills in X 2
Horizontal drills in Y 2
Saw aggregate fix in X-direction
Cantilever machine 1
Machine table Pod and rail table
Number of table bars 6
Vacuum pump 1
Capacity vacuum pump m³/h 100
Safety device Light barrier
CE-mark 1
Total connection kW 17
Availability from about August 2016
Operating status still in production use
Condition good
